View In:   ArcGIS Online Map Viewer

Name: Signal

Display Field: FROM_DATE

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Indiana Signal(s) point Inventory created as an ESRI point shapefile consisting of a Feature point geometry. The data set was compiled by Road Inventory of the Indiana GIS Department of Transportation (INDOT) . Dataset is classified as sde Feature Class. The Feature Class is projected Coordinate System: NAD 1983, UTM, Zone 16 N. The Projections is Transverse Mercator.</SPAN></P><P><SPAN>Each Signal(s) point Inventory is placed as to Position, Route, and Measure; and is classified as to Signal Type, Mode, Phase, Section, and Preemption. Signal Mode is described as Signal, Flasher, and Stop Sign. Signal Type is described as Uncorrdinated Fixed Time, Uncoordinated Traffic Actuated, Coordinated Progressive, Coordinated Real-Time Adaptive, and No Signal Systems Exist. Point Inventory is Dated as of 2014-2015.</SPAN></P></DIV></DIV></DIV>

Service Item Id: c988f88416844ddebaf9d286f4b9fc44

Copyright Text: The Signal is an sde Feature Class created by Indiana GIS Department of Transportation (INDOT)

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 417007.975
YMin: 4193772.25
XMax: 688603.315
YMax: 4623882.5294
Spatial Reference: 26916  (26916)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [135, 59, 59, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• FROM_DATE ( type: esriFieldTypeDate, alias: From Date, editable: true, nullable: true, length: 8, defaultValue: null, modelName: From_Date )
• TO_DATE ( type: esriFieldTypeDate, alias: To Date, editable: true, nullable: true, length: 8, defaultValue: null, modelName: To_Date )
• EVENT_ID ( type: esriFieldTypeString, alias: EventID, editable: true, nullable: true, length: 50, defaultValue: null, modelName: Event_ID )
• ROUTE_ID ( type: esriFieldTypeString, alias: RouteID, editable: true, nullable: true, length: 17, defaultValue: null, modelName: Route_ID )
• MEASURE ( type: esriFieldTypeDouble, alias: Measure, editable: true, nullable: true, defaultValue: null, modelName: Measure )
• RECORD_STATUS ( type: esriFieldTypeSmallInteger, alias: Record_Status, editable: true, nullable: true, defaultValue: null, modelName: Record_Status , Coded Values: [0: Work In Progress] , [1: Proposed] , [2: Withdrawn] , ...5 more... )
• SIGNAL_TYPE ( type: esriFieldTypeSmallInteger, alias: Signal_Type, editable: true, nullable: true, defaultValue: null, modelName: Signal_Type , Coded Values: [1: Uncoordinated Fixed Time] , [2: Uncoordinated Traffic Actuated] , [3: Coordinated Progressive] , ...2 more... )
• SIGNAL_COMM ( type: esriFieldTypeString, alias: Signal Type, editable: true, nullable: true, length: 50, defaultValue: null, modelName: Signal_COMM )
• SIGNAL_MODE ( type: esriFieldTypeSmallInteger, alias: Signal_Mode, editable: true, nullable: true, defaultValue: null, modelName: Signal_Mode , Coded Values: [1: Signal] , [2: Flasher] , [3: Stop Sign] )
• SIGNAL_PHASE ( type: esriFieldTypeString, alias: Signal_Phase, editable: true, nullable: true, length: 50, defaultValue: null, modelName: Signal_Phase )
• SIGNAL_PREEMP ( type: esriFieldTypeString, alias: Signal_Preemp, editable: true, nullable: true, length: 3, defaultValue: null, modelName: Signal_Preemp )
• SIGNAL_DETECT ( type: esriFieldTypeString, alias: Signal_Detect, editable: true, nullable: true, length: 3, defaultValue: null, modelName: Signal_Detect , Coded Values: [No: Not Actuated] , [Yes: Yes Actuated] )
• CREATED_BY ( type: esriFieldTypeString, alias: Created By, editable: false, nullable: true, length: 25, defaultValue: null, modelName: Created_by )
• DATE_CREATED ( type: esriFieldTypeDate, alias: Date Created, editable: false, nullable: true, length: 8, defaultValue: null, modelName: Date_Created )
• EDITED_BY ( type: esriFieldTypeString, alias: Edited By, editable: false, nullable: true, length: 25, defaultValue: null, modelName: Edited_By )
• DATE_EDITED ( type: esriFieldTypeDate, alias: Date Edited, editable: false, nullable: true, length: 8, defaultValue: null, modelName: Date_Edited )
• LOCERROR ( type: esriFieldTypeString, alias: LocError, editable: true, nullable: true, length: 100, defaultValue: null, modelName: LocError )
• DATE_ATTR_EFFECTIVE ( type: esriFieldTypeDate, alias: Date Attribute Effective, editable: true, nullable: true, length: 8, defaultValue: null, modelName: DATE_ATTR_EFFECTIVE )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GLOBALID )

Templates:

• Name: Signal
  Description:
  Prototype:
  DATE_ATTR_EFFECTIVE: null
  FROM_DATE: null
  TO_DATE: null
  EVENT_ID: null
  ROUTE_ID: null
  MEASURE: null
  RECORD_STATUS: null
  SIGNAL_TYPE: null
  SIGNAL_COMM: null
  SIGNAL_MODE: null
  SIGNAL_PHASE: null
  SIGNAL_PREEMP: null
  SIGNAL_DETECT: null
  LOCERROR: null

  Drawing Tool: esriFeatureEditToolPoint

Capabilities: Query,Extract,ChangeTracking

Sync Can Return Changes: true

Is Data Versioned: true

Supports Rollback On Failure: false

Supports ApplyEdits With Global Ids: true

Supports OidReservation: true

Edit Fields Info:

• Creation Date Field: DATE_CREATED
• Creator Field: CREATED_BY
• Edit Date Field: DATE_EDITED
• Editor Field: EDITED_BY

Supports Query With Historic Moment: true

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
